Sealed Crimp and Shrink Butt Connector
Features a translucent, adhesive-lined Polyolefin tubing that seals against dirt, debris and moisture. Connection becomes water tight to prevent corrosion.
Inner barrel is seamless to provide better wire contact, superior tensile strength and increased current flow.
Shrink ratio: 3 to 1
Temperature to facilitate shrinking of Polyolefin - 275F
Tensile strength: 2200 PSI
UL Voltage rating: 600 Volts
Environment operating temperature range: -67F to 230F
Conforms to automotive and industrial manufactures specifications for wiring repairs.
Product is RoHs Compliant.
For best results: Use heat device of at least 1000F. Don't overheat tubing. Don't isolate flame. Distribute heat evenly over tubing.
