Disk Spring Washer

AISI 301 Stainless

DIN 2093

SKU: 00-Y2093-A1
Minimum Box: Select a valid option

This configuration is not available. Make another selection.

This configuration is not available. Make another selection.

DIN 2093 Disc Spring Washer – AISI 301 Stainless Steel

DIN 2093 disc spring washers are conical-shaped spring washers designed to provide high load capacity and controlled deflection in bolted assemblies. Their precision-engineered disc shape allows them to absorb axial loads, compensate for thermal expansion, reduce vibration effects, and maintain consistent clamping force under dynamic conditions. DIN 2093 washers are manufactured to standardized dimensions and load characteristics, making them suitable for demanding mechanical and industrial applications requiring reliable spring performance.

Material

Manufactured from AISI 301 stainless steel, these disc spring washers offer excellent spring properties together with reliable corrosion resistance. AISI 301 stainless steel provides high strength and elasticity after forming while maintaining good resistance to rust and oxidation in humid and mildly corrosive environments. The natural stainless finish ensures long-term durability and dependable performance in applications exposed to moisture, vibration, or repeated loading cycles.

Use

DIN 2093 disc spring washers are widely used in machinery, heavy equipment, pumps, valves, flange assemblies, electrical systems, and industrial fastening applications where maintaining preload is critical. They are particularly effective in assemblies exposed to vibration, thermal cycling, or dynamic loading conditions that can cause conventional fasteners to loosen over time. Their corrosion-resistant stainless construction makes them suitable for industrial, marine, energy, and maintenance applications requiring long service life and consistent clamping performance.

Included SKUs:

Y2093-A1-6X12.5X0.7-200, Y2093-A1-10X20X0.8-100, Y2093-A1-8X20X0.5-100, Y2093-A1-10X20X0.5-100, Y2093-A1-6X12X0.35-200, Y2093-A1-10X20X1.1-100, Y2093-A1-4X8X0.2-200, Y2093-A1-14X18X0.8-50, Y2093-A1-18X35.5X0.9-50, Y2093-A1-5X10X0.4-200, Y2093-A1-16X31.5X1.75-50, Y2093-A1-20X40X2.25-25, Y2093-A1-10X20X0.9-100, Y2093-A1-12X25X0.9-50, Y2093-A1-6X18X0.4-100, Y2093-A1-11X22.5X0.6-100, Y2093-A1-8X15X0.8-100, Y2093-A1-12X25X1.5-50, Y2093-A1-7X14X0.8-200, Y2093-A1-18X35.5X2-50, Y2093-A1-4X12X0.5-200, Y2093-A1-22X45X1.25-25, Y2093-A1-14X28X1.5-50, Y2093-A1-25X50X3-25, Y2093-A1-14X28X1-50, Y2093-A1-18X35.5X1.25-50, Y2093-A1-8X16X0.6-100, Y2093-A1-10X20X0.6-100, Y2093-A1-22X45X2.5-25, Y2093-A1-16X31.5X0.8-50, Y2093-A1-9X18X0.7-100, Y2093-A1-6X12.5X0.5-200, Y2093-A1-3X6X0.3-200, Y2093-A1-20X40X1-25, Y2093-A1-4X12X0.4-200, Y2093-A1-25X50X2-25, Y2093-A1-16X31.5X1.25-50, Y2093-A1-8X16X0.4-100, Y2093-A1-4X8X0.4-200, Y2093-A1-11X22.5X1.25-100, Y2093-A1-9X18X1-100, Y2093-A1-7X14X0.5-200, Y2093-A1-20X40X2-25, Y2093-A1-5X10X0.25-200, Y2093-A1-20X40X1.5-25, Y2093-A1-10X20X1.0-100, Y2093-A1-7X14X0.35-200, Y2093-A1-22X45X1.75-25, Y2093-A1-4X8X0.3-200, Y2093-A1-11X22.5X0.8-100, Y2093-A1-25X50X1.25-25, Y2093-A1-5X10X0.5-200, Y2093-A1-12X25X0.7-50, Y2093-A1-6X12X0.5-200, Y2093-A1-8X16X0.9-100, Y2093-A1-3X8X0.5-200, Y2093-A1-9X18X0.45-100

Special Order Product Policy

  • Special Order Parts are Available ONLY in Box Quantities and are Not Returnable & Cannot be cancelled after confirmation.
  • Free Domestic Shipping over $99 will be offered in your special order quote if applicable.
  • For a full list of Special Order Policies: Please Click Here
